GSFM 1100-2000 Full Automatic Turret Type High Speed Extrusion Laminating Machine

Application: For thin paper, non-woven fabric, aluminum foil, metalized film, BOPP/PET, etc; Main features: 1.PLC man-machine interface centralized control, machine, electricity, gas integrated design. 2.High precision, non edge imported original die head

Send Inquiry
Shared to

Application: For thin paper, non-woven fabric, aluminum foil, metalized film, BOPP/PET, etc



Main features:

1.PLC man-machine interface centralized control, machine, electricity, gas integrated design.

2.High precision, non edge imported original die head

3.Auto height-adjusting extruder

4.High speed and efficient mixing equipment (US technology)

5.New technology static mixing device (Italy Technology)

6.Quick Hydraulic filter-screen exchange device, auto loading system.

7.Optional to equip with dry type composite system, with the function of dry composite machine

8.And can be matched with a single extruder, Twin Extruder, extruder, multilayer coextrusion



Main technical parameters:

machinery specification

1100/90mm、1300/100mm 、1500/105mm、 1800/110mm

speed of coating film

300m/min

suitable coating resin film

LDPE、PP、 EVA 、EAA

suitable base material

BOPP、BOPET、BOPA、CPP、CPE、PAPER、AL、NONWOVEN

width of coating film

1100mm、1300mm、1500mm、1800mm

thickness of coating film

0.012~0.1mm

inaccuracy thickness of coating film

≦±5%

complex cooling roller

Φ800mm

screw specification

（L/D）Φ90：33、Φ100：33、Φ105:33；Φ110:33

main unwinding diameter

Φ800-1500mm

diameter of auxiliary unwinding

Φ600mm

diameter of rewinding

Φ800-1700mm
